Power Module Comparison
Please check this brief comparison table of our power lineup, if you have any questions please contact us
 |  |  | |
|---|---|---|---|
| Power modules | Power Zero | CAN Power | High current PWR |
| Status | in production | in production | in production |
| PN | M10077 | M10104 | M10121 |
| HW revision | A | A | A |
| Comments | |||
| Power | |||
| Input voltage (max) | 50.4V (12S) | 50.4V (12S) | 58.8V (14S) |
| Current rating | 90A | 60A | 150A |
| Max current burst | 100A | 90A | 200A |
| Sensor type | Hall | Hall | Hall |
| BEC [V@C] | 5.3V@2A | 5.3V@3A | 5.2V@3A (fixed) |
| BEC2 | ~ | ~ | 5,6,7,8,9,12V@3A (selectable) |
| Mechanical | |||
| Dimensions (Length x Width) | 18 mm x 18 mm | 26 mm x 26 mm | 50 mm x 50 mm |
| Dimensions (Height) | 20.8 mm | ||
| Screw Pattern | 45 mm x 45 mm | ||
| Screw Size | M3 | ||
| Weight | 2.5g | 5.90g | 24.1 g |
| Available interfaces | |||
| Analog | yes | no | yes |
| CAN | no | yes | no |
| I2C | no | optional | no |
