Flight Controllers

Autopilots

Complete documentation for 3DR's advanced flight controllers. From professional-grade systems to compact solutions.

View Documentation

Comparison below

Please check this brief comparison table of our autopilot lineup, if you have any questions please contact us.

Select products to compare

Control N1ActiveControl Zero OEMActivePixracer ProActiveControl ZeroActiveControl Zero ClassicMTO

Select allClear all

CancelApply

Show / hide columns

Image locked Model locked Part #StatusIMUBaroMagPWMUARTSPII2CSDIOEthProcessorRAMFlashExt. MemoryConnectorsTemp. RangeDimensionsWeightNeeds Carrier

Show allHide optional

CancelApply

Compare Columns

	Model	Part #	Status	IMU	Baro	Mag	PWM	UART	SPI	I2C	SDIO	Eth	Processor	RAM	Flash	Ext. Memory	Connectors	Temp. Range	Dimensions	Weight	Needs Carrier
	Control N1	R0024	Active	IIM-42653IIM-42653	DPS368	AK09940A	12	7	1	2	1	No	H743	1MB	2MB	8MB (Page EEPROM)	Amphenol BergStak	-40 to 85°C	17.6 × 28 × 3.8 mm	2.3 g	Yes
	Control Zero OEM	M10059	Active	BMI088ICM-20602ICM-20948	DPS368	AK09916	8	6	1	3	1	No	H743	1MB	2MB	256kB (F-RAM)	Samtec FTM series (1mm)	-40 to 85C	20 mm x 34.7 mm x 6.8 mm	3.5g / 3.8g w SD Card	Yes
	Pixracer Pro	M10064	Active	BMI085ICM-20602ICM-20948	DPS368	AK09916	8	6	1	1	1	No	H743	1MB	2MB	256kB (F-RAM)	JST-GH + 0.1" headers	-20 to 65C	36.6 mm x 36.6 mm x 10.3 mm	8.92 g	No
	Control Zero	M10058	Active	BMI088ICM-20602ICM-20948	DPS310	AK09916	8	5	1	1	1	No	H743	1MB	2MB	256kB (F-RAM)	Molex PicoClasp	-20 to 65C	25.9 mm x 40 mm x 13.2 mm	18.14g / 34.94g w Case	No
	Control Zero Classic	M10048	MTO	BMI088ICM-20602ICM-20948	DPS310	AK09916	12	5	1	2	1	No	H743	1MB	2MB	256kB (F-RAM)	DF13 + 0.1" headers	-40 to 85C	49.9 mm x 81.2 mm x 14.9 mm	37.6g	No

MTO - Made to Order

Please check this brief comparison table of our CN1 carrier lineup, if you have any questions please contact us.

Select products to compare

N1 Carrier board 1 - CubyActiveN1 Carrier board 2 - LongyActiveN1 Carrier board 3 - FPVActiveN1 Carrier board 4 - WingActiveN1 Prototyping BoardActiveCN1 to CZ OEM AdapterActive

Select allClear all

CancelApply

Show / hide columns

Image locked Board locked StatusPart #HW Rev.L × WHeightScrew PatternScrew SizeWeightUSBPWMUARTCANI2CSPIFeaturesInput V.OutputMax. Current

Show allHide optional

CancelApply

Compare Columns

	Board	Status	Part #	HW Rev.	L × W	Height	Screw Pattern	Screw Size	Weight	USB	PWM	UART	CAN	I2C	SPI	Features	Input V.	Output	Max. Current
	N1 Carrier board 1 - Cuby	Active	R0026	A.2	38.6 mm x 38.4 mm	4.8 mm	34.1 mm x 33 mm	M2.5	4.4 g	C	12		2	pads	1	SMTSO-M1.6 optional	5V	5V, 2A
	N1 Carrier board 2 - Longy	Active	R0027	A.2	81 mm x 20.8 mm	5 mm	66 mm x 15 mm	M2.5	6.5g (4.5 g without pins)	C	12	6	2	2 in pads	1	SMTSO-M1.6 optional	5V
	N1 Carrier board 3 - FPV	Active	R0033	A.1	37 mm x 37 mm	9.5 mm	30.5 mm x 30.5 mm	M3 (w/grommets)	9.5 g	C	10		1	GPS + pads	none	Analog OSD, Camera IN/OUT pads. Solder jumpers to select SPI6/UART6 output	2 to 6S
	N1 Carrier board 4 - Wing	Active	R0036	A.1	70 mm x 36.5 mm	11.54 mm		M2.5		C	12	6	2	2		Analog OSD, Dual ESC BEC, Selectable 5V/7.5V PWM logic	6.4V – 28V (6S)	5V at 600mA
	N1 Prototyping Board	Active	R0037	A.1	95 mm x 37.73 mm	10.9mm (w/pins)		M2.5		2x C (USB + Console UART)	12	6	2	2	1	Full pin breakout, breadboard compatible, dual debug interfaces, micro SD	5V (USB or Battery)	5V at 1.5A, 3.3V at 600mA
	CN1 to CZ OEM Adapter	Active	R0034	A.1	34.5 mm x 20 mm	8.3 mm (9.6 mm mated height)													—

Please check this brief comparison table of our CZ OEM carrier lineup, if you have any questions please contact us.

Select products to compare

CZ ReferenceActiveCZ StickActiveCZ PrototypingActiveQuad ZeroActive

Select allClear all

CancelApply

Show / hide columns

Image locked Board locked StatusPart #HW Rev.L × WHeightScrew PatternScrew SizeWeightUSBPWMUARTCANI2CSPIFeaturesInput V.OutputMax. Current

Show allHide optional

CancelApply

Compare Columns

	Board	Status	Part #	HW Rev.	L × W	Height	Screw Pattern	Screw Size	Weight	USB	PWM	UART	CAN	I2C	SPI	Features	Input V.	Output	Max. Current
	CZ Reference	Active	M10066	B	63.7 mm x 32.4 mm	4.8 mm	58 x 25 mm	M3	4.52 g	B micro	8	2	2	pads	1	Safety switch	3S	5.2V, 3A	40A
	CZ Stick	Active	M10062	B	81.5 mm x 21.6 mm	4.81 mm	66 mm x 15 mm	M2.5	6.5g (4.7 g without pins)	B micro	8	2 or 4	2	2 in pads	~	Safety switch
	CZ Prototyping	Active	M10060	D	67 mm x 55 mm	5.5 mm	46 mm x 42 mm	M3	11.6 g	B micro	8	1	2	3	1	~
	Quad Zero	Active	M10112	E	97.7 mm x 56.6 mm	6 mm	45 mm x 52 mm	M2	9.2 g	B micro	5	3	1	1	0	Voltage and current monitor, VL53L0X ToF sensor (down), 4×12A BLHeli_S ESC
